NMD90
Construction: Two or three-conductor cable with bare grounding conductor; heat-resistant PVC & nylon insulation for single conductors, overall PVC outer jacket.
Conductor: Annealed soft solid/stranded bare copper
Insulation: Flame-retardant PVC with nylon sheath
Jacket: PVC overall jacket, colour coded by AWG size
Voltage Rating: 300 Volts
Temperature Rating: Max 90°C; Min installation temp -25°C (2-core), -10°C (3-core)
Compliance Standards: CSA FT1, CSA C22.2 No.48-M90, RoHS compliant
Send Inquiry
Technical
Application
Exposed or concealed wiring in dry/damp residential locations; general residential power circuits, lighting and branch wiring.
NMWU Cable
Package
